| Part Number 型号 |
Emitting Color 发光颜色 |
λp (nm)/x |
λp (nm)/y |
Lens Color 胶体颜色 |
VF (V) | IF=mA | IV (mcd) | Viewing Angle | |||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Typ. | Max. | Min. | Typ. | 2θ ½ | |||||||
| 304URM-53-01D | Super Bright Red | 620 | 630 | White Diffused | 2.00 | 2.20 | 20 | 150 | 300 | 60 | |
| 304UAM-53-01D | Super Bright Orange | 600 | 610 | White Diffused | 2.00 | 2.20 | 150 | 300 | |||
| 304UYM-53-01D | Super Bright Yellow | 588 | 593 | White Diffused | 2.00 | 2.20 | 150 | 300 | |||
| 304YGM-53-01D | Super Yellow Green | 568 | 573 | White Diffused | 2.00 | 2.20 | 60 | 120 | |||
| 304PGM-53-01D | Pure Green | 520 | 525 | White Diffused | 2.80 | 3.20 | 3000 | 6000 | |||
| 304UBM-53-01D | Blue | 465 | 470 | White Diffused | 2.80 | 3.20 | 400 | 700 | |||
| 304UWM-53-01D | Cool White | X:0.28 | Y:0.28 | White Diffused | 2.80 | 3.20 | 3000 | 5000 | |||
| 304CWM-53-01D | Neutral White | X:0.33 | Y:0.32 | White Diffused | 2.80 | 3.20 | 3000 | 5000 | |||
| 304YWM-53-01D | Warm White | X:0.43 | Y:0.40 | White Diffused | 2.80 | 3.20 | 3000 | 5000 | |||
| 3mm插件系列可以按照客户需求定制如：粉红光，冰蓝光，冰绿光，金黄光等 | |||||||||||
