| Part Number 型号 |
Emitting Color 发光颜色 |
λp (nm)/x |
λp (nm)/y |
Lens Color 胶体颜色 |
VF (V) | IF=mA | IV (mcd) | Viewing Angle 2θ ½ |
|||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Typ. | Max. | Min. | Typ. | 2θ ½ | |||||||
| 309URYGC-53-01A | Super Bright Red | 620 | 630 | Water Clear | 2.00 | 2.20 | 20 | 600 | 1000 | 30 | |
| Super Yellow Green | 568 | 573 | Water Clear | 2.00 | 2.20 | 160 | 260 | ||||
| 309URPGC-53-01A | Super Bright Red | 620 | 630 | Water Clear | 2.00 | 2.20 | 600 | 1000 | |||
| Pure Green | 520 | 525 | Water Clear | 2.80 | 3.20 | 8000 | 15000 | ||||
| 309URUBC-53-01A | Super Bright Red | 620 | 630 | Water Clear | 2.00 | 2.20 | 600 | 1000 | |||
| Blue | 465 | 470 | Water Clear | 2.80 | 3.20 | 1500 | 2500 | ||||
| 309URUWC-53-01A | Super Bright Red | 620 | 630 | Water Clear | 2.00 | 2.20 | 600 | 1000 | |||
| Cool White | X:0.28 | Y:0.28 | Water Clear | 2.80 | 3.20 | 5000 | 8000 | ||||
| 3mm插件系列可以按照客户需求定制如：粉红光，冰蓝光，冰绿光，金黄光等 | |||||||||||
